Dual Track Spiral Conveyor
Two conveying tracks on one spiral structure, where a single column has to carry two runs.
The machine
The two tracks share one column and one footprint. They can run in the same direction, or be configured with opposing travel directions — one track up and one down.
Best suited for
- Two flows that have to change level in the space one spiral would occupy
- Holding product between two process steps, rather than simply lifting it
-
Application example
Hot-oil bottles
NEXUS supplied a Dual Track Spiral Conveyor for hot-oil bottles. Both tracks conveyed products in the same direction within one shared spiral structure.
Technical data
Specifications and options
Figures are for the standard machine. Confirm them for your goods, layout and configuration.
Technical Specifications
Specifications
- Direction
- Upwards, downwards, or bidirectional in one machine
- Tracks
- Two independent tracks, each driven by its own motor
- Frame
- Stainless steel, or mild steel painted in a double coat — primer and topcoat
- Load capacity
- Load capacity is specified for the product and conveyor configuration.
Inlet & outlet configurations
Choose the inlet and outlet arrangement to suit your line.
Equipment
Equipment
- Slat chain
- Designed and made by NEXUS
Discuss your application
Send us the product dimensions and weight, required throughput, elevation change, available footprint and the equipment at either end. NEXUS will configure the conveying system around your line.
